 Features
- Full-color MFP with 15 Sec. Warmup time
- Up to 30 ppm color printing/copying
- Up to 40 ppm monochrome printing/copying
- Network Scanner / Scan to Email Standard
- Convenient 4 Gb. SD Memory Card Interface
- Advanced Security Functions
|
Specifications
Specifications - General
| Fusing Method |
Induction Heating (IH) System |
| Inverting Automatic Document Feeder |
70 sheets (A4, 80 g/m²) |
| Paper Feed |
Std. 550-sheet paper tray unit x 2 + 100-sheet bypass
Optional paper tray: 550 sheets x 2
Max. 2,250 sheets with option |
| System Hard Disk (Standard) |
80 GB (Shared) |
| Power Requirements |
AC 220 V-240 V, 50/60 Hz |
| Power Consumption |
Max.: Less than 1.5 kW
Power saver mode: Approx. 75 W
Sleep mode: Approx. 35 W |
| Warm-up Time (20°C) |
Approx. 15 sec. (From Power Saver mode/Sleep mode)
Approx. 19 sec. (From Main power switch ON) |
Dimensions (W x D x H)
(Excluding optional equipment) |
656 mm x 825 mm x 933 mm
(Including Automatic Document Feeder and ADF mounting bracket) |
| Weight (Excluding optional equipment) |
Approx. 164 kg |
Specifications - Digital Copier
| First Copy Time |
B/W: Approx. 6.2 sec. (A4)
Color: Approx. 10.3 sec. (A4) |
| Resolution |
Max. 600 dpi |
| Multi Copy Speed |
B/W: Up to 40 cpm
Color: Up to 30 cpm |
| Copy Size |
A3 - A5 |
| Copy Ratio |
Enlargement: (fixed)
200%, 173%, 141%, 122%, 115%
Reduction: (fixed)
87%, 82%, 71%, 58%, 50% |
| Zoom (variable) |
25%~400% (in 1% increments) |
| Exposure Control |
Text, Text / Photo, Photo |
| Sort Memory |
Standard: 12 GB |
Specifications - Printer
| Network Printer Interface |
Ethernet 10Base-T/100Base-TX |
| Local Printer Interface |
USB 2.0 |
| Printer Language |
PCL 6 Emulation (Standard)
Adobe(R) PostScript(R)3TM (Option) |
| Printing Speed |
B/W: Up to 40 ppm
Color: Up to 30 ppm |
| Printing Resolution |
1,200 dpi x 1,200 dpi, 600 dpi x 600 dpi (PCL, PS) |
| Printer Memory |
512 MB / 768 MB |
| PCL/PS Spool Memory |
2 GB |
| Compatible Operating Systems |
WWindows(R) XP, 2000, Vista, Server 2003, 98, Me, Windows NT(R) 4.0, MacOS 8.6-10.4 (PS3 Only), Linux (PS3 Only), Unix (PS3 Only) |
Specifications - Network Scanner / Scan-to-Email
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Maximum Scanning Size |
A3 |
| Scanning Speed |
45 ipm |
| Scanning Resolution |
200 dpi x 200 dpi, 300 dpi x 300 dpi, 400 dpi x 400 dpi, 600 dpi x 600 dpi |
| Data Format |
B/W: TIFF, PDF
Color: JPEG, PDF, Compressed PDF (300 x 300 dpi only) |
Address Book Capacity
(including Network scanner, Scan-to-Email, G3 Fax and Internet Fax) |
200 stations
Max. 1000 stations |
Specifications - G3 Fax (Option) / Internet Fax (Option)
| Compatibility |
G3 Fax: ITU-T Group 3, ECM
Internet Fax: ITU-T T.37, IETF RFC 3965 |
| Communication Protocol |
TCP/IP, SMTP, POP3, MIME, LDAP (Internet Fax) |
| Modem Speed |
33.6 kbps - 2.4 kbps with automatic fallback (G3 Fax) |
| Coding Scheme |
JBIG / MMR / MR / MH (Conforms to ITU-T Recommendations) |
| Scanning Speed |
Approx. 0.7 sec. (A4 portrait in Standard or Fine mode with ADF) |
| Transmission Speed |
Approx. 2.9 sec. (A4) |
| Maximum Original Size |
A3 |
| Effective Scanning Width |
292 mm |
| Recording Resolution |
600 x 600 dpi |
| Standard Memory |
3 MB (approx. 180 pages based on ITU-T Image No.1 using Standard Resolution) |
